Zone Allocation to Areas
Whilst within the zone programming section zones may be allocated to areas. This
may be one single area or multiple (common) areas.
If a zone is allocated to more than one area it is then a common area zone
and the following logic is applied:-
If any area that is assigned to the zone is unset then the zone is not
active.
If all areas that are assigned to a zone are set then the zone is
active.
If any area that is assigned to the zone is in exit then the zone is also in exit
(zone type will still apply).
If any area that is assigned to the zone is in entry then the zone is also in
entry (zone type will still apply).
Zones
Three zone wiring modes are available depending on standard selected on power up.
16(2 Wire). If required, this configuration may be programmed for 16 two wire zones.
In this case, two zones should be reserved for global tampers and the remaining 14
zones are then programmable for the desired zone types. All zones marked as AZ are
positive loops and all zones marked as TZ are negative loops. Your global tamper
loops must be of opposite polarity to the zones it is protecting.
Cannot be used in Grade 3 installations.
8(4 Wire). If required, this configuration may be programmed for 8 four wire zones.
Wire 8 individual zones with their own tampers.
Page 7
