Understanding Part/Test/Chime
Part Sets
Three Part Set modes are available on all models. These are Part1, Part 2 & Part3.
Part Set 1 may consist of a suite of zones that have been programmed as Part1 by the
engineer.
Part Set 2 may consist of a suite of zones that have been programmed as Part2 by the
engineer.
Part Set 3 combines all zones in Part1 & Part2 to form the third Part Set. This requires
no additional programming by the engineer other than Part1 & Part2 programming.
Note: Zones programmed into a Part Set will be removed (omitted) from the
system when that Part Set is used.
Test
Zones programmed as Test will not activate the system when it is set. Activations of
test zones when the system is set will record to the log and will show ‘Test Fail’ when
the system is unset.
Test should only be used for zones that will not be activated when the system is set.
Do not use test on any E/E or Entry Route zones.
Note: After a zone has been put on test it will be automatically taken off test
after 20 successful Set / Unset operations.
Chime 1 & 2
Any number of zones may be programmed as chime 1 or 2 by the engineer. Chime is
usually used as a low level warning when the system is unset that someone has
entered a protected area.
Chime may be turned On and Off by the end user as required
If Exit Terminators are fitted to the system the Exit Terminator zone may be
programmed for chime thus doubling as a door bell.
Walk (Forced Walk Test)
When FWT is used the zones programmed as Walk must be walk tested before the
system will start to set. FWT Mode (option 130) must be programmed to ‘All Sets’ or
‘Full Set Only’ for FWT to operate. A FWT Bypass time is available via option 129. This
allows up to 90 minutes between the system being unset and then set without having
to walk test the system again.
