GARDTEC 816 - Programming Setting Modes

Page 96
Programming Setting Modes
Setting Modes are the modes that the control panel will use to set the system for a
particular type of set. An example of this may be that the Full Set Modes is
programmed as Final Exit Door (door opening and closing during exit will set te panel)
whilst the Setting Mode for Part Set 1 is timed. Each type of Set (Full, Part 1, Part 2,
Part 3) may have its own Setting Mode.
1) Enter into Engineer Mode
To do this follow Steps 1 to 4 on page 79
With the display showing:-
2) Press No. The display will show:-
3) Press Yes. The display will show:-
4) Press Yes. The display will show:-
(A1 indicates Area 1).
5) Press No twice. The display will show:-
6) Enter the time you require as the Exit Time
(in seconds), followed by Yes.
The display will show, for example:-
Program . . . . _ _ _
Zones ?
Program . . . . _ _ _
Setting Modes ?
Program Setting
for FULL set ?
F-EXIT A1 =30s
=Set by TIME
F-EXIT A1 >_ _s
=Set by TIME
F-EXIT A1 =20s
>Set by TIME
