Zone Expander Card Ident & Zone Allocation
The panel and each individual card may be programmed as four wire, two wire or two
wire EOL wiring modes. All zones on ZEX 1 start at 21 and all zones on ZEX 2 start at
31 and so on. The zone allocation for the different modes is given below.
Group 1 Expanders using SAD1 from panel to SAD1 terminal on Expander
EXP1 JP1 On 4 Wire 2 Wire 2 Wire EOL
AZ1 Zone 21 21 21
AZ2 Zone 22 22 22
AZ3 Zone 23 23 23
AZ4 Zone 24 24 24
TZ1 Zone 21 Tamper 25 25
TZ2 Zone 22 Tamper 26 26
TZ3 Zone 23 Tamper 27 27
TZ4 Zone 24 Tamper 28 28
EXP2 JP2 On 4 Wire 2 Wire 2 Wire EOL
AZ1 Zone 31 31 31
AZ2 Zone 32 32 32
AZ3 Zone 33 33 33
AZ4 Zone 34 34 34
TZ1 Zone 31 Tamper 35 35
TZ2 Zone 32 Tamper 36 36
TZ3 Zone 33 Tamper 37 37
TZ4 Zone 34 Tamper 38 38
EXP3 JP3 On 4 Wire 2 Wire 2 Wire EOL
AZ1 Zone 41 41 41
AZ2 Zone 42 42 42
AZ3 Zone 43 43 43
AZ4 Zone 44 44 44
TZ1 Zone 41 Tamper 45 45
TZ2 Zone 42 Tamper 46 46
TZ3 Zone 43 Tamper 47 47
TZ4 Zone 44 Tamper 48 48
EXP4 JP4 On 4 Wire 2 Wire 2 Wire EOL
AZ1 Zone 51 51 51
AZ2 Zone 52 52 52
AZ3 Zone 53 53 53
AZ4 Zone 54 54 54
TZ1 Zone 51 Tamper 55 55
TZ2 Zone 52 Tamper 56 56
TZ3 Zone 53 Tamper 57 57
TZ4 Zone 54 Tamper 58 58
