Page 21
Keypad Jumper Options - Non 4 Wire Type
Keypad Numbering (ident)
All keypads must have the ident jumper in position in order that the system can
recognise the keypad it is communicating with. This information is written to the log as
the system is set and unset. If greater than four RKPs are required on the 872 the Multi
Keypad option should be programmed to On. Two keypads may then share the same
ident. It should be noted that LCD & LED RKPs may not share the same ident.
LCD and LED versions
Four jumper links are fitted on the LCD and LED versions of the keypad. On earlier
Standard keypads the legend was slightly different as shown in Fig 11.
Fig 11. Keypad ident legends.
Note: Contour keypads fitted with ACE have two additional jumpers for the ACE
functions, these are:-
US This jumper is the user select. With the jumper link removed each
ACE key fob will occupy one user code from the system, this is
termed as high security mode.
With the jumper link in position the ACE will occupy one user code
from the system but up to fourteen key fobs may be programmed
into the ACE, this is normal security mode.
NVM With this jumper in position the NVM contents will be cleared when
the unit is powered up. All codes will be lost
Note: On Keypads from 2004 the US jumper is not present. All Ace
Fobs or Prox are High Security
The ident jumper should be positioned across the pins in one of the positions before
the system is powered up.
Gardtec 800 Series Compact RKP
The keypad ident on the compact RKP is through JP 1 to JP 4 respectively.
KEYPAD No.
4
3
2
1
A4
A3
A2
A1
JP1
JP2
JP3
JP4
Early Legend Standard/Contour Legend
(Use left hand legend)
PR5892 Rev11 800 Series Eng Ref 15.qxd 16/11/2006 11:20 Page 21
