A full list of options that are available for the code types are given in the user manual.
As a general guide for this section, the codes for the Gardtec 872 are split into two
groups, Global and Area codes. Codes allocated to these groups are as follows:-
Global Codes (Controlling All Areas).
Master
Main
Set Only
Engineer
If any area is set, entering a global code (not Set Only or Cleaner) will unset all areas.
If all areas are unset, entering a global code followed by YES (or code then NO YES if
Engineer code is used) will give the option to set all areas.
The global codes with the exception of Set Only also have other options. More details
of these options are given in the user manual.
Area Codes (Controlling Specific Areas)
Cleaner (Area 0)
Area 2 Main 6
Area 3 Main 7
Main 1 Area 4
Main 2 Area 5
Main 3 Area 6
Main 4 Area 7
Main 5 Area 1
Group Master
Group Main
Group Area
These area codes will only control their specific areas. Area codes are 'low level codes'
and have no user options, they will however allow for the part setting of each area.
Areas 1 to 7 may have up to 3 part sets suites (groups of zones). If part set 1 is used
zones programmed into the part 1 suite will be removed (omitted), if part set 2 is used
zones programmed into the part 2 suite will be removed and if part set 3 is used zones
programmed into both part 1 and part 2 suites will be removed, no programming is
required for part 3 as it combines zones in part 1 and part 2.
