RealVü 3D Forward Sonar View

This sonar view shows a three-dimensional view of what is in front of the transducer. This view can be used

when you are stationary and you need to see the bottom and the fish approaching the boat.

Color legend

Boat

Ping indicator

Fish

Bottom

Range
