Garmin ECHOMAP UHD2 User Manual

Introduction
WARNING
See the Important Safety and Product Information guide in the product box for product warnings and other
important information.
ECHOMAP UHD 60 Front View
Power key
Automatic backlight sensor
Keys
microSD
®
memory card slot
NOTICE
Each time you place the device in the cradle, you should make sure the device is firmly secured in the cradle,
the cables are fully pushed into the device and cradle, and the locking bracket is snapped firmly closed. There is
an audible click when the locking bracket is installed correctly. If the cables are not fully seated and the device
is not firmly secured, it can lose power or stop working. The device can also fall out of the cradle and become
damaged if it is not firmly secured.
Introduction 1

Garmin ECHOMAP UHD2 Specifications

General

Sonar	Yes
GPS	Yes
Water Rating	IPX7
NMEA 0183 Input Ports	1
NMEA 0183 Output Ports	1
Sonar Recording	Yes
Sonar History Rewind	Yes
Display Resolution	800 x 480 pixels
Preloaded Maps	Yes
Connectivity	Wi-Fi
Mounting Options	Flush mount
Antenna	Internal
Transmitter Power	500 W (RMS)
Sonar Frequencies	Traditional: 77/200 kHz
Maximum Depth	2, 300 ft (Traditional)
Waypoints	5, 000
Routes	100
