Gate Titan User Guide

16
WWW.GATEE.EU
USER GUIDE
You will need:
• cross-head screwdriver
• flat-blade screwdriver
• metal file or milling machine
solvent
grease
programming card or USB-Link and PC
•
•
•
01
Remove the gearbox from the AEG body.
Follow the steps below in order to mount the TITAN Drop-in Module:
02
Disassemble your gearbox, take out all the internals.
03
Clean the gearbox case using solvent.
04
Pay attention to the marked area. If you see that it is not smooth, use a metal file or
grindstone to prepare the surface.
The gearbox surface should be smooth, with no sharp edges which would damage the
TITAN.

Gate Titan Specifications

General

MOSFET	Yes
Battery protection	Yes
Trigger sensitivity adjustment	Yes
Pre-cocking	Yes
ROF control	Yes
Active brake	Yes
Diagnostic system	Yes
Programmable	Yes
Cycle Detection	Yes
Compatibility	V2 Gearbox
Low current consumption in sleep mode	0.2mA
Connectivity	USB-Link, Blu-Link
Fire Modes	Semi, Burst
Bluetooth support	Yes
