Gate Titan User Guide

17
WWW.GATEE.EU
USER GUIDE
05
06
07
08
Detach the drop-in module carefully.
Place the bottom board on the bottom
part of the gearbox. Do not use a screw
yet. Check if the bottom board is laid flat
in the gearbox.
Make sure the electronic components do
not touch the gearbox case.
Use the insulation (black) washer from
the kit. ATTENTION! The insulation
washer must protect the circuit board.
The metal screw and metal washer
cannot touch the board directly. It can
result in short-circuit and TITAN damage
which is not covered by the warranty.

Gate Titan Specifications

General

MOSFET	Yes
Battery protection	Yes
Trigger sensitivity adjustment	Yes
Pre-cocking	Yes
ROF control	Yes
Active brake	Yes
Diagnostic system	Yes
Programmable	Yes
Cycle Detection	Yes
Compatibility	V2 Gearbox
Low current consumption in sleep mode	0.2mA
Connectivity	USB-Link, Blu-Link
Fire Modes	Semi, Burst
Bluetooth support	Yes
