Gate Titan User Guide

18
WWW.GATEE.EU
USER GUIDE
09
10
11
SCREW SCREW
METAL WASHER INSULATION WASHER
INSULATION WASHER
METAL WASHER
GEARBOX GEARBOX
Screw on the bottom board to the case.
Use the original screw or the one from the
TITAN kit.
Check if the screw sticks out of the
gearbox.
If so, add metal washer(s) included in the
kit. Make sure that the metal washer is
placed between the screw and the
insulation washer. It cannot touch the
circuit board directly.
CAUTION! Placing the washers in wrong order will cause short circuit and permanent
damage to the TITAN, which is not covered by the warranty.

Gate Titan Specifications

General

MOSFET	Yes
Battery protection	Yes
Trigger sensitivity adjustment	Yes
Pre-cocking	Yes
ROF control	Yes
Active brake	Yes
Diagnostic system	Yes
Programmable	Yes
Cycle Detection	Yes
Compatibility	V2 Gearbox
Low current consumption in sleep mode	0.2mA
Connectivity	USB-Link, Blu-Link
Fire Modes	Semi, Burst
Bluetooth support	Yes
