Gate Titan User Guide

12
19
WWW.GATEE.EU
USER GUIDE
13
14
15
GEAR SENSOR
TRIGGER SENSOR
Check if the top board fits gearbox
without any problems.
Loosen the screw. Adjust the position of
the bottom board.
The distance between the board and the
bearing should be similar as indicated in
the marked area.
Make sure the marked areas are not
covered by board or wires.
Check if sensors are clean and not
covered by wires.

Gate Titan Specifications

General

MOSFET	Yes
Battery protection	Yes
Trigger sensitivity adjustment	Yes
Pre-cocking	Yes
ROF control	Yes
Active brake	Yes
Diagnostic system	Yes
Programmable	Yes
Cycle Detection	Yes
Compatibility	V2 Gearbox
Low current consumption in sleep mode	0.2mA
Connectivity	USB-Link, Blu-Link
Fire Modes	Semi, Burst
Bluetooth support	Yes
