Gate Titan User Guide

20
WWW.GATEE.EU
USER GUIDE
19
18
17
16
Some gearboxes need modification.
Check if your gearbox has the marked
pins. If so, remove them.
Check if both parts of the gearbox fit
together perfectly.
Mount the trigger without spring. Insert
the TITAN top board. Close the gearbox.
Carefully check if the trigger moves
smoothly and does not touch any TITAN's
components.
Mount the sector gear, trigger with spring
and top TITAN board. Make sure that the
gear does not touch TITAN.

Gate Titan Specifications

General

MOSFET	Yes
Battery protection	Yes
Trigger sensitivity adjustment	Yes
Pre-cocking	Yes
ROF control	Yes
Active brake	Yes
Diagnostic system	Yes
Programmable	Yes
Cycle Detection	Yes
Compatibility	V2 Gearbox
Low current consumption in sleep mode	0.2mA
Connectivity	USB-Link, Blu-Link
Fire Modes	Semi, Burst
Bluetooth support	Yes
