50
WWW.GATEE.EU
USER GUIDE
E01 - E06 GROUP
E01
E02
E03
E04
E05
E06
Main transistor error.
Break transistor error.
Voltage measurement error.
Temperature sensor error.
Amplifier error.
Other error.
1. Clear the DTC and check if the error still appears.
2. Contact GATE support team at titan@gatee.eu
E01 - E06 DTC indicate internal errors.
POSSIBLE REASON: WHAT TO DO:
E07
VIBRATIONS: 3x
TITAN did not detect the sector gear and after 0.2s it cut off the motor.
1. Disassemble the gearbox and check if the gear
sensors are clean.
2. Carry out the sensors' inspection using the Tactical
Programming Card or GCS.
3. In case of a dirty or damaged gear sensor you may
set CYCLE DETECTION to OFF.
1. Gear sensor is damaged or is dirty.
2. Sector gear is damaged.
3. Sector gear is jammed.
4. Motor is damaged.
POSSIBLE REASON: WHAT TO DO:
E09
When battery is being connected, TITAN detects a pulled trigger.
1. Release the trigger.
2. Using the Tactical Programming Card or GCS set a
lower trigger sensitivity.
3. Clean the trigger sensors.
1. Trigger is pulled while connecting the battery.
2. Trigger sensitivity is set too high.
3. Trigger sensors are dirty.
POSSIBLE REASON: WHAT TO DO:
VIBRATIONS: 4x
E08
Fire selector error.
1. Insert the gearbox into the body.
2. Modify the selector plate using the sticker from the
installation kit (p. 21).
1. Outside light affects the fire selector sensor.
2. The selector plate is not reflecting the light.
POSSIBLE REASON: WHAT TO DO:
VIBRATIONS: 3x
