Y35 HD v3 User Manual & Install Guide
101 of 156
Sensor Number: 5
▪ Sensor Name – LEFTTURN
▪ OSD Name – LT
Sensor Number: 6
▪ Sensor Name – RIGHTTRN
▪ OSD Name – RT
Sensor Number: 7
▪ Sensor Name – EXTRA1
▪ OSD Name – E1
Sensor Number: 8
▪ Sensor Name – EXTRA2
▪ OSD Name – E2
Trigger Source
DEFAULT SETTINGS:
▪ Source Voltage
Sensor Uses
This feature allows you to easily copy the
configuration settings for this sensor to
another selected sensor. Use the drop list to
select a sensor number – then clicking the
(Copy) button will replicate the current sensor
settings to the selected sensor.
DEFAULT SETTINGS:
▪ None
Serial
RS232-1
The first associated drop list allows the user to
configure the port function:
▪ None
▪ Extend
▪ Control Panel
▪ Old Control Panel
▪ T&H Sensor
▪ GPS Data
▪ 3-Axis Sensor
▪ External GPS
▪ CP4
▪ Keyboard
▪ EXT Sensors
▪ RS232 Sensors
▪ Tri color DA
▪ Driver alert
