Y35 HD v3 User Manual & Install Guide
90 of 156
▪ None
DEFAULT SETTINGS:
▪ None
Note:
- If the Sub-Record, Alarm Backup, or Mirror
Record options are selected, then the SD
Write Resource Ratio, Record Storage, and
Channel parameters become available.
Storage Dual Stream
Recording
DEFAULT SETTINGS:
▪ Checkbox - Unselected
Storage Dual Stream
Split
DEFAULT SETTINGS:
▪ Disabled/not applicable
Main Stream
Channel
Drop list which displays the list of available
camera channels. Selecting one of them will
display the currently set configuration values,
and allow you to modify them.
These configuration values are channel specific.
You will need to select each channel in turn and
configure them separately.
Notes:
- For quick configuration, the copy function
allows you to easily copy the settings of the
current channel to another channel.
Channel Name
Alphanumeric text field for setting the channel
name. This is useful for giving the channel an
easily remembered and/or location-specific
name.
You may input up to a maximum of:
▪ 5 characters
Notes:
- Channels 1 to 4 are analog/analogHD
channels.
- Channel 5 is a Digital IP camera channel.
DEFAULT SETTINGS:
▪ Channel 1 – set name as – CH1
▪ Channel 2 – set name as – CH2
▪ Channel 3 – set name as – CH3
▪ Channel 4 – set name as – CH4
▪ Channel 5 – set name as – CH5
