Enable
Checkbox – if selected, enables this channel for
inclusion into the main stream recording.
DEFAULT SETTINGS:
▪ For channels 1 to 5, only enable the
channels which actually have cameras
connected. Please note that the system
will show a video loss message on
channels which are enabled, but do not
have a connected camera (i.e., no
incoming video stream).
Resolution
Drop list for selecting the resolution to record
the video on this channel (applicable to
channels 1 to 4):
▪ CIF (352x240)
▪ WCIF (464x240)
▪ HD1 (704x240)
▪ WHD1 (928x240)
▪ D1 (704x480)
▪ WD1 (928x480)
▪ 720p (1280x720)
▪ 1080p (1920x1080)
DEFAULT SETTINGS:
▪ For channels 1 to 4 (analog camera
channels), the camera with the highest
resolution should automatically be
detected and used. (i.e. If a S31AHD is
connected, the resolution should set to
720p, if a S32AHD is connected; 1080p
etc)
▪ For the Digital IP Camera (channel 5), it
should automatically detect and use
the camera with the highest resolution.
Percentage of Main
Stream
DEFAULT SETTINGS:
▪ 22.2%
Encode Standard
DEFAULT SETTINGS:
▪ H264
Note – Read GLOSSARY for more information
Frame Rate
Drop list allowing you to select the frame rate
(in terms of frames per second) that you would
like to record at.
DEFAULT SETTINGS:
For all channels (1 to 5), set the following:
▪ 15
