Maintenance instructions
6.2 QS4 Technical Reference Manual
Pseudo point definitions
Table 6-1: Main Panel pseudo points
LCD Indication Event Type Definition
Panel xx Card Communications Trouble CPU has failed to communicate with the option
card at address xx.
Panel 01 Reset Extension Monitor/Trouble Signature loop is still resetting.
Panel 01 Service Active Trouble Trouble Service group was restored with a device still in
the active condition.
Pnl 0x Database Incompatible Trouble Changes made to the system programming on the
control panel were not updated in this unit.
Panel 01 Reboot Fault Control panel CPU restarted unexpectedly.
Panel 0x, CH1 Communications Trouble
Annunciator is not communicating on RS485
channel 1.
Panel 01 Task Failure Trouble Internal processing fault.
Card xx Setup Mismatch Trouble CPU encountered problem configuring the option
card at address xx.
Dailer Setup Mismatch Trouble
A problem has occurred with the CPU configuring
the dialer card.
Power Supply Setup Mismatch Trouble A problem has occurred with the CPU configuring
the POWER supply card.
Panel 01 LED/Switch display Trouble LED/Switch card is not connected.
Panel 0x, CH2 Communications Trouble Annunciator is not communicating on RS485
channel 2.
Pnl 01 Database Supervision Trouble Internal CPU memory failure
Panel 01 Code Supervision Trouble Internal CPU memory failure
Panel 01, Call For Service Trouble Internal CPU processing error
Panel 01, ROM Supervision Trouble Internal CPU memory failure
Panel 01 RS232 Port Fault Trouble
Panel 01 Unexpected Card Trouble
CPU detected an option card not defined in the
database.
Panel 01 Switch Latched Trouble Button either on the main display or on an
LED/Switch card has been pressed too long.
Panel 01 Loop Database Fault Trouble Internal CPU memory failure with Signature data.
Table 6-2: Remote Annunciator pseudo points
LCD Indication Event Type Definition
Ann 0x Service Active Trouble Trouble Indicates that a device was left in an active
condition after service group has restored.
Ann 0x Database Incompatible Trouble Indicates that the data
Annunciator 0x Reboot Fault Trouble
Indicates CPU has restarted due to internal
processing failure.
