Installation

2.24 QS4 Technical Reference Manual

Connecting a service computer

Connection of a service computer to the

control panel requires programming

cable P/N 260097, ordered separately.

Connection of a service computer to a

remote annunciator requires

programming cable P/N 360136 and a

RJ–11 to DB9 adapter P/N 240507,

both ordered separately.

RTS

PS6

COM

NOT USED

DB-9F

REAR VIEW

P/N 260097
