Programming instructions
4.26 QS4 Technical Reference Manual
Setting up a Zone
Before you begin
Before you begin, you should complete a Zone Programming
Worksheet (Figure 4-9) for each Zone. Keep a copy for your
records. You will also need to refer to the Output Group
programming worksheets.
To set up a Zone:
1. On the control panel, press Menu.
2. Choose Login then enter the password required for Level 4
access.
3. Choose Program > Configure > Zone.
4. To program a new Zone, choose Add, and then choose a
zone type (Alarm, Supervisory, or Monitor).
— or —
Choose Edit, select an existing zone from the pick list, and
then press Enter.
Configure the Zone
1. Choose Message, scan in the message text, and then
press Enter.
2. Choose Members, then for each device that comprises the
Zone:
Choose Device Address, then enter the member's device
number from the worksheet
— or —
Choose Enter Serial#, scan in or enter the member's serial
number.
3. Choose Review to verify which devices you added to the
Zone. If you added any devices in error, delete them.
4. Choose Output Group > Add, then select the Output group
from the pick list that contains the responses you want
activated, and then press Enter.
Repeat for each Output group you want to add.
5. Choose Review to verify which Output groups you added to
the Zone. If you added any Output groups in error, remove
them.
6 For coded systems, choose Coding, and then enter the
Zone Code.
