Operating instructions
3.2 QS4 Technical Reference Manual
Instructions for the Level 1 operator (public mode access)
Tasks that do not require you to log in
What is it you want to do This is how you do it
Silence the panel trouble buzzer
Press Panel Silence.
Get a list of all the active points on a
panel
1. Press Status.
2. Choose All Active to get a list of all the active points.
Choose Alarm to get a list of only the active alarm points.
Choose Supervisory to get a list of only the active
supervisory points.
Choose Monitor to get a list of only the active monitor
points.
3. Press DEL to backspace the cursor then enter the panel
number.
4. Choose Display to view the list on the CPU/Display unit.
— or —
Choose Printer to print the list.
Identify points that are in trouble
1. Press Status.
2. Choose Trouble
3. Press DEL to backspace the cursor then enter the panel
number.
4. Choose Display to view the list on the CPU/Display unit.
— or —
Choose Printer to print the list.
Identify active points in a Service
Group that is being tested
1. Press Status.
2. Choose Test.
3. Press DEL to backspace the cursor then enter the panel
number.
4. Choose Display to view the list on the CPU/Display unit.
— or —
Choose Printer to print the list.
