Programming instructions
4.18 QS4 Technical Reference Manual
What is it you want to do This is how you do it
Enter location message text for a circuit on a
SIGA module
1. On the Configure menu, choose Cards > Edit
and then enter the card address number of the
loop controller.
2. Choose Config Module > Edit > Enter Serial #
and then scan or enter the serial number of the
module.
3. For a single-address module or the first
address of a dual-address module, choose
Device 1.
— or —
For the second address of a dual-address
module, choose Device 2.
4. Choose Message, scan in the text, and then
press Enter.
5. Choose Exit.
Change the device type for a circuit on a SIGA
module
Note: The device types shown in the pick lists vary
depending on the SIGA module. The device types
shown in the pick lists for the second address of a
dual-address module also vary depending on the
device type chosen for the first address.
1. On the Configure menu, choose Cards > Edit
and then enter the card address number of the
loop controller.
2. Choose Config Module > Edit > Enter Serial #
and then scan or enter the serial number of the
module.
3. For a single-address module or the first
address of a dual-address module, choose
Device 1.
— or —
For the second address of a dual-address
module, choose Device 2.
4. Choose Type, select a device type from the
pick list, and then press Enter.
5. Choose Exit.
