Ge Est QS4 - Page 87

Programming instructions
QS4 Technical Reference Manual 4.29
Job Name: Page
of
Panel: Card:
001 Device Type:
Text Message: 1)
2)
002 Device Type:
Text Message: 1)
2)
003 Device Type:
Text Message: 1)
2)
004 Device Type:
Text Message: 1)
2)
005 Device Type:
Text Message: 1)
2)
006 Device Type:
Text Message: 1)
2)
007 Device Type:
Text Message: 1)
2)
008 Device Type:
Text Message: 1)
2)
IDC 001
IDC/NAC 004
IDC 003
IDC 002
IDC 005
IDC/NAC 008
IDC 006
IDC 007
Defaults: Alarm for IDC 001 – 003 and IDC 005 – 007,
Common Alarm Output for IDC/NAC 004, Visual for
IDC/NAC 008
Figure 4-2: ZA8–2 Programming Worksheet
