3 Installation
32551-IMG rev 6 GE Healthcare 33
Checking the ECS:
1 The LEDs H1 (+34V), H2 (+15V), H4 (+5V) and H5 (if the C-arm is
shifted) on the ECS Driver Board turn on.
2 The C-arm brake release buttons in the c-arm handles do not
operate if the C-arm is shifted. The brake can be released only if the
C-arm is in the lowest position (the photo interrupter has entered the
slot and the microswitch on the side of the ECS mechanism is
activated).
SUPPLY BOARD Code 32030-IMG
TP7 to TP1 brake 26 Vdc
TP7 to TP2 Unreg +34Vdc 33 Vdc
TP7 to TP4 Vin CPU 23 Vdc
TP7 to TP5 +AEC in +20 Vdc
TP7 to TP6 -AEC in -20 Vdc
TP8 to TP9 lamp (AC volts) 10.5 Vac
CPU BOARD Code 32245-IMG
across diode D3 Vin CPU 5.1 Vdc
C&Z BOARD Code 33035-IMG
TP1 to TP12 Vin C&Z 34 Vdc
TP2 to TP12 15 Vdc
TP3 to TP12 Vin bucky 24 Vdc
TP4 to TP13 Comp low speed ref. adjustable +15 Vdc
TP5 to TP13 Comp high speed ref. adjustable +15 Vdc
TP8 to TP9 Comp up/dn 22 Vdc*
TP10 to TP11 Vert up/dn 25 Vdc*
FILAMENT CONTROL BOARD Code 32225-IMG
TP12 to TP9 Unreg Dcin 35 Vdc
TP12 to TP10 +Vdc +15 Vdc
TP12 to TP11 -Vdc -15 Vdc
INVERTER BOARD Code 32220-IMG
TP29 to TP27 +Vdc +15 Vdc
TP29 to TP30 -Vdc -15 Vdc
C-ARM CONTROL BOARD Code 30310-IMG
TP2 to TP3 +Vdc +5 Vdc
