18 GE INFORMATION D20MX HARDWARE USER’S MANUAL
CHAPTER 1: BEFORE YOU START
Table 3 provides the License Group legend.
Table 3: D20MX license group
NOTE
The license group is an option in the D20MX order code. Refer to Table 10 and Table 11 for
details. Ordering a D20MX with a particular license group option enables all applications in
that group to run on the D20MX.
Table 4 lists the embedded images included in the D20MX firmware.
B015 Bridgeman Allows applications to communicate with other peer
applications. Automatically routing messages to the
destination application. Intended to work within layered
software architectures. Provides the routing functions of a
network layer, but does not add a network layer header to
outgoing messages.
530
B023 DNP V3.00 DCA The Distributed Network Protocol V3.00 DCA acts as the
master to one or more remote devices using the DNP V3.00
protocol.
755 Yes
B034-0N Redundant Monitor for
D20MX
Monitors CCU states and initiates failover. Also, receives
command requests to perform database synchronization,
switchover and failover.
300 Yes
B045-0 D20AC WESMAINT II+
Display Screens
Provides D20AC WESMAINT II+ displays. 101
B052-0N DNP Internet Data Link for
D20MX
DNP V3.00 data link over internet. 351
B058-0 IEC 870-5 Data Link FT 1.2 primary data link configuration 231 New
B060-0 IEC 870-5-101 DCA Acts as a master (primary) communication device, initiating
data exchanges. It is capable of sending control commands
to the remote devices, and processing data autonomously
collected by the data link layer.
210 New
B071-0 WESMAINT File Upload Uploads files via the WESMAINT port as S records or using
ZMODEM.
200
B085 IEC Balanced Data Link Provides services to send and receive messages using the
IEC 60870-5 FT 1.2 Balanced Protocol over point-to-point
links, with support for a dial-up modem. Works with one
user in point-to-point configurations, or multiple users in
dial-up configurations.
130 New
B086-0 IEC 60870-5-104 Data Link Provides a service to reliably transfer IEC 60870-5-101
Application Service Data Units (ASDU) over a TCP/IP network.
Implements this service using the transport layer interface
protocol IEC 60870-5-104.
131 New
B100-0 Internet Protocol Stack Configuration of the LAN 141
B152-1N IP Redundancy Monitor
DTA for D20MX
Provides health and active pseudo DI points for LAN Ports. 200 Yes
SAN0001 Application Definitions
B009 Mailbox DTA System point conversion application. 401
B021N DNP V3.00 DPA for D20MX The Distributed Network Protocol (DNP) DPA enables master
stations to retrieve and modify local data using the DNP
V3.00 Application Layer Protocol.
990 Yes
SAN0002 Application Definitions
B009 Mailbox DTA System point conversion application. 310
B021N DNP V3.00 DPA for D20MX The Distributed Network Protocol (DNP) DPA enables master
stations to retrieve and modify local data using the DNP
V3.00 Application Layer Protocol.
913 Yes
License
Group
D20MX
Application
ID
Application Name Description Application
Definition
Version
Changed
LIcense Group Group Description
001 D2X Classic Applications
