CHAPTER 1: BEFORE YOU START
D20MX HARDWARE USER’S MANUAL GE INFORMATION 19
The Version Image column indicates the image versions in the SAN0001 and SAN0002
files.
Table 4: D20MX embedded images
Firmware/FPGA versions
Table 5 lists the firmware, FPGA and other version information.
Table 5: Firmware/FPGA versions information
D20 chassis
For a detailed description of the D20 chassis options and components, refer to
Familiarization chapter in the D20/D200 Installation and Operation Guide, 994-0078. The
D20MX supports the two versions of the D20 chassis listed in
Table 6.
Table 6: Types of D20 chassis
D20 non-VME The D20 non-VME single-slot chassis consists of the following:
• D20MX processor board
• Modem slots
• Power supply with switch and fuses; see Figure 1.
ID
Image Name Description Version
Changed
S032 D20S Peripheral Board (supports B003) D20S Peripheral Board Code 303
S033 D20A Peripheral Board (supports B003) D20A Peripheral Board Code 301
S034 D20K Peripheral Board (supports B003) D20K Peripheral Board Code 306
S035 D20C Peripheral Board (supports B003) D20C Peripheral Board Code 307
S055-0 D20AC Peripheral Board (supports B003) D20AC Peripheral Board Code 108
Component Version ID Type ID Date How to Find
JMON 1.0.630-
2238
N/A N/A Wed Dec 12,
2012 11:06AM
“D20 Version” shown
during cold boot
sequence.
Board N/A Board D20MX N/A “Board ID” shown via
SHELL command: si
Local Bus
FPGA
3.02 N/A N/A N/A “FPGA version” shown via
SHELL command: si
NVRAM FPGA 15 File N/A N/A “NVRAM Rev” shown via
SHELL command: si
VxWorks O/S
and BSP
v1.20 Build 33d61705e0e7a6e7 Jul 17 2013,
21:00:12
SHELL command: ver
Application v1.20 Build d9dc1bd692eedad4 Jul 17 2013 -
20:28:26
SHELL command: ver
Bootrom v1.1/0 Build 55959fd4c8a2db7f Mar 11 2013
15:50:15
SHELL command: ver
Type GE part number Description
D20 non-VME
1 slot horizontal
500-0305 Chassis with backplane, external power connections, and
seven serial I/O ports
D20 VME
5 slot horizontal
500-0280 Chassis with five-card VME backplane
