GE D20MX User Manual

D20MX HARDWARE USER’S MANUAL GE INFORMATION 31
D20MX Processor
Chapter 2: Installing the D20MX
Installing the D20MX
This chapter covers the following topics:
• D20 chassis layouts
• Overview of the steps and tools required to install the D20MX
• Retrofitting the D20MX in an existing D20
• Grounding the D20MX and connecting the power supply
D20 chassis layouts
Installation of the D20MX can be performed with one of three D20 chassis layouts; see
“Installation steps” on page 33.
The D20 non-VME chassis front panel layouts for the D20MX upgrade kits comprise:
• A D20 containing a D20MX with front Ethernet connectors; see Figure 6.
• A D20 containing a D20MX with front Fiber Optic connectors; see Figure 7.
• A D20 containing a D20MX with rear Fiber Optic connectors; see Figure 8.
