98 GE INFORMATION D20MX HARDWARE USER’S MANUAL
APPENDIX B: STANDARDS & PROTECTION
Table 56: Safety publications
Table 57: Environmental standards
IEC 61000-4-6
IEC 60255-22-6
IEC 61850-3: clause 5.7.1.1
Immunity to conducted disturbances,
induced by radio-frequency fields
150 kHz to 80 MHz: 10Vrms
IEC 60255-22-1 1 MHz burst immunity test
IEC 61000-4-8 Power frequency magnetic field
immunity test
IEC 61000-4-9 Pulse magnetic field immunity test
IEC 61000-4-12 Ring wave
IEC 61000-4-11 Voltage dips, short interruptions and
voltage variations immunity tests
IEC 61000-4-16
IEC 61850-3: clause 5.7.1.3
Test for immunity to conducted, common
mode disturbances in the frequency
range 0 Hz to 150 kHz
30Vrms, 300Vrms
IEC 61000-4-17 Ripple on DC input power port immunity
test
IEC 61000-4-29+ Voltage dips, short interruptions and
voltage variations on DC input power
port immunity test
This standard only applies when using
high voltage DC as the source (100
V DC
to300 V DC).
Standard Name Description Test Specification
IEC 61010-1 Safety requirements for electrical
equipment for measurement, control and
laboratory use - General requirements
IEC 60255-5 Insulation coordination for measuring
relays and protection equipment-
Requirements and tests
Dielectric and Resistance
measurements not applicable
due to design (TVS in circuit)
Standard Name Description Test Specification
IEC 60068-2-1 Cold 144 hours powered at - 20 °C
IEC 60068-2-2 Dry Heat 144 hours powered at + 70 °C
IEC 60068-2-6 Vibration (sinusoidal) A logarithmic sweep from 10 Hz to
150
Hz to 10 Hz at 1 oct/min for 1
sweep cycle in the 3 orthogonal axes.
Acceleration level 1 g
IEC 600255-21-2 Shock - Operating Response Test
Shock - Non-Operating Withstand
Test
Pulse shape: Half sine Pulse duration:
11 mS
- Operating Response Test:
Acceleration level: 5 g's
- Non-Operating Withstand Test:
Acceleration level: 15 g's
3 pulses per polarity per axis for a total
of 18 pulses
IEC 600255-21-2 Bump – Non operating test Pulse shape: Half sine Pulse duration:
16
mS Acceleration level: 10 g's
1000 pulses per polarity per axis for a
total of 6000 pulses
IEC 60068-2-30 Damp heat, cyclic (12 h + 12 h
cycle)
Standard Name Description Test Specification
