CHAPTER 1: BEFORE YOU START
D20MX INSTRUCTION MANUAL GE INFORMATION 19
001 A199-0N 106 HR6000/XA-21 (DPA) for
D20MX
Communicates with one or more hosts using
the Harris HR6000/XA-21 protocol, emulating
several HR6000/XA-21 LRUs. Supports multiple
communication ports, multiple LRUs per
communication port, and redundant porting.
B003 751 D.20 Peripheral Link DCA The D.20 Peripheral Link is responsible for
surveillance and control of digital and analog
values in the D.20 I/O peripherals.
B008-1 311 System Point Database Maintains the database of system points in the
RTU.
B012N 201 IRIG-B DCA for D20MX Provides Universal Time Coordination (UTC)
using the IRIG-B pulse frame, as specified by
IRIG Standard 200-04 September 2004 Edition.
B013 560 DNP V3.00 Data Link Provides services for software applications to
send and receive messages using the
Distributed Network Protocol (DNP) V3.00 Data
Link protocol and the DNP V3.00 Transport
Functions
B014-1N 520 WESMAINT II+ for D20MX RTU maintenance facility.
B015 530 Bridgeman Allows applications to communicate with other
peer applications. Automatically routing
messages to the destination application.
Intended to work within layered software
architectures. Provides the routing functions of
a network layer, but does not add a network
layer header to outgoing messages.
B023N 761 DNP V3.00 DCA The Distributed Network Protocol V3.00 DCA
acts as the master to one or more remote
devices using the DNP V3.00 protocol.
B034N 203 Redundant Monitor for
D20MX
Monitors CCU states and initiates failover. Also,
receives command requests to perform
database synchronization, switchover and
failover.
B045-0 101 D20AC WESMAINT II+
Display Screens
Provides D20AC WESMAINT II+ displays
B052-0N 351 DNP Internet Data Link for
D20MX
DNP V3.00 data link over internet
B058-0N 231 IEC 870-5 Data Link for
D20MX
FT 1.2 primary data link configuration
B060-0 210 IEC 870-5-101 DCA Acts as a master (primary) communication
device, initiating data exchanges. It is capable
of sending control commands to the remote
devices, and processing data autonomously
collected by the data link layer.
B071-0 200 WESMAINT File Upload Uploads files via the WESMAINT port as S
records or using ZMODEM.
B080-0 214 IEC 60870-5-103 DCA Monitors and controls devices using the IEC
60870-5-103 protocol.
002 B082-0N 311 LogicLinx Executor WARP
for D20MX (Ethernet
capable)
The LogicLinx executor is responsible for
executing PLC programs written using the
LogicLinx PLC (IEC 1131-3 compliant) editor.
B085-0 130 IEC Balanced Data Link Provides services to send and receive
messages using the IEC 60870-5 FT 1.2
Balanced Protocol over point-to-point links,
with support for a dial-up modem. Works with
one user in point-to-point configurations, or
multiple users in dial-up configurations.
B086-0 131 IEC 60870-5-104 Data Link Provides a service to reliably transfer IEC
60870-5-101 Application Service Data Units
(ASDU) over a TCP/IP network. Implements this
service using the transport layer interface
protocol IEC 60870-5-104.
License
Group
D20MX
Application ID
Base D20 Classic
Application Version †
Application Name Description
