ECG
(continued)
■ Relearn:
• It is important to RELEARN anytime the
electrode configuration is adjusted.
• Select the ECG parameter box.
• Select RELEARN.
• Remember to ensure that there is a clean ECG
signal displayed when relearning a rhythm.
• Current ECG templates are now updated.
■ If the Problem Continues:
• Select the ECG Parameter Window.
• Select VIEW ALL ECG to determine the best
display lead. Select the lead with the greatest
amplitude. (Remember that a minimum of
0.5 mV of amplitude in one direction, positive or
negative, is required for QRS detection).
• Select DISPLAY LEAD: II.
• Select the desired display lead.
• Select LD ANALYSIS MULTI-LEAD.
• Select SINGLE LEAD.
• All arrhythmia interpretations will now be based
on this single ECG lead.
TROUBLESHOOTING and
FREQUENTLY ASKED QUESTIONS
