March 2008
1-12 Programming Site Data
Entering System Data for
a Channel (cont.)
7. Press [F1]-[F4] to select the desired number of Decimal Digits
(digits to the right of the decimal point) in the volumetric flow rate
display.
8. Use the
[F1]-[F4] and [←] and [→] keys to select the desired
Totalizer Units for the totalized flow rate display.
The option bar above shows English units. If Metric units are
specified in the
GLOBL menu, these will appear instead.
The abbreviations and definitions of all the available totalizer units
are shown in Table 1-3 below. The choices shown on the option bar in
the prompt screen above are determined by the selections made at the
previous
SYSTEM UNITS prompt screen.
9. Press
[F1]-[F4] to select the desired number of Totalizer Decimal
Digits (digits to the right of the decimal point) in the totalized flow
display.
Table 1-3: Totalizer Units Options
English Totalizer Units Metric Totalizer Units
Gal - U.S. Gallons L - Liters
MGAL - Mega U.S. gallons ML - Megaliters
ft
3
- Cubic Feet m
3
- Cubic Meters
Mft
3
- Mega Cubic Feet Mm
3
- Mega Cubic Meters
BBL - Barrels BBL - Barrels
MBBL - Megabarrels MBBL - Megabarrels
Acre-inches
Acre-feet
