B-22 F60 Feeder Protection System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
26D5 IEC 61850 GGIO5 uinteger Input 6 Operand --- --- --- F612 0
26D6 IEC 61850 GGIO5 uinteger Input 7 Operand --- --- --- F612 0
26D7 IEC 61850 GGIO5 uinteger Input 8 Operand --- --- --- F612 0
26D8 IEC 61850 GGIO5 uinteger Input 9 Operand --- --- --- F612 0
26D9 IEC 61850 GGIO5 uinteger Input 10 Operand --- --- --- F612 0
26DA IEC 61850 GGIO5 uinteger Input 11 Operand --- --- --- F612 0
26DB IEC 61850 GGIO5 uinteger Input 12 Operand --- --- --- F612 0
26DC IEC 61850 GGIO5 uinteger Input 13 Operand --- --- --- F612 0
26DD IEC 61850 GGIO5 uinteger Input 14 Operand --- --- --- F612 0
26DE IEC 61850 GGIO5 uinteger Input 15 Operand --- --- --- F612 0
26DF IEC 61850 GGIO5 uinteger Input 16 Operand --- --- --- F612 0
IEC 61850 Received Integers (Read Only Actual Values) (16 modules)
26F0 IEC 61850 Received uinteger 1 0 to 4294967295 --- 1 F003 0
26F2 IEC 61850 Received uinteger 2 0 to 4294967295 --- 1 F003 0
26F4 IEC 61850 Received uinteger 3 0 to 4294967295 --- 1 F003 0
26F6 IEC 61850 Received uinteger 4 0 to 4294967295 --- 1 F003 0
26F8 IEC 61850 Received uinteger 5 0 to 4294967295 --- 1 F003 0
26FA IEC 61850 Received uinteger 6 0 to 4294967295 --- 1 F003 0
26FC IEC 61850 Received uinteger 7 0 to 4294967295 --- 1 F003 0
26FE IEC 61850 Received uinteger 8 0 to 4294967295 --- 1 F003 0
2700 IEC 61850 Received uinteger 9 0 to 4294967295 --- 1 F003 0
2702 IEC 61850 Received uinteger 10 0 to 4294967295 --- 1 F003 0
2704 IEC 61850 Received uinteger 11 0 to 4294967295 --- 1 F003 0
2706 IEC 61850 Received uinteger 12 0 to 4294967295 --- 1 F003 0
2708 IEC 61850 Received uinteger 13 0 to 4294967295 --- 1 F003 0
270A IEC 61850 Received uinteger 14 0 to 4294967295 --- 1 F003 0
270C IEC 61850 Received uinteger 15 0 to 4294967295 --- 1 F003 0
270E IEC 61850 Received uinteger 16 0 to 4294967295 --- 1 F003 0
Source Current THD and Harmonics (Read Only) (4 modules)
2800 Ia THD for Source 1 0 to 99.9 --- 0.1 F001 0
2801 Ia Harmonics for Source 1 - 2nd to 25th (24 items) 0 to 99.9 --- 0.1 F001 0
2821 Ib THD for Source 1 0 to 99.9 --- 0.1 F001 0
2822 Ib Harmonics for Source 1 - 2nd to 25th (24 items) 0 to 99.9 --- 0.1 F001 0
283A Reserved (8 items) 0 to 0.1 --- 0.1 F001 0
2842 Ic THD for Source 1 0 to 99.9 --- 0.1 F001 0
2843 Ic Harmonics for Source 1 - 2nd to 25th (24 items) 0 to 99.9 --- 0.1 F001 0
285B Reserved (8 items) 0 to 0.1 --- 0.1 F001 0
2863 ...Repeated for Source 2
28C6 ...Repeated for Source 3
2929 ...Repeated for Source 4
Expanded FlexStates (Read Only)
2B00 FlexStates, one per register (256 items) 0 to 1 --- 1 F108 0 (Off)
Expanded Contact Input/Output States (Read Only)
2D00 Contact Input States, one per register (96 items) 0 to 1 --- 1 F108 0 (Off)
2D80 Contact Output States, one per register (64 items) 0 to 1 --- 1 F108 0 (Off)
2E00 Virtual Output States, one per register (96 items) 0 to 1 --- 1 F108 0 (Off)
Expanded Remote Input/Output Status (Read Only)
2F00 Remote Device States, one per register (32 items) 0 to 1 --- 1 F155 0 (Offline)
2F80 Remote Input States, one per register (64 items) 0 to 1 --- 1 F108 0 (Off)
Oscillography Values (Read Only)
3000 Oscillography Number of Triggers 0 to 65535 --- 1 F001 0
3001 Oscillography Available Records 0 to 65535 --- 1 F001 0
3002 Oscillography Last Cleared Date 0 to 400000000 --- 1 F050 0
3004 Oscillography Number Of Cycles Per Record 0 to 65535 --- 1 F001 0
Table B–10: MODBUS MEMORY MAP (Sheet 14 of 70)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
