GE Multilin F60 Feeder Protection System B-21
APPENDIX B B.4 MEMORY MAPPING
B
Remote Double-Point Status Inputs (Read/Write Setting Registers) (5 modules)
2540 Remote Double-point Status Input 1 Device 1 to 32 --- 1 F001 1
2541 Remote Double-point Status Input 1 Item 0 to 64 --- 1 F606 0 (None)
2542 Remote Double-point Status Input 1 Name 1 to 64 --- 1 F205 "RemDPS Ip 1"
2548 Remote Double-point Status Input 1 Events 0 to 1 --- 1 F102 0 (Disabled)
2549 ... Repeated for Remote Double-point Status Input 2
2552 ... Repeated for Remote Double-point Status Input 3
255B ... Repeated for Remote Double-point Status Input 4
2564 ... Repeated for Remote Double-point Status Input 5
Phasor Measurement Unit Actual Values (Read Only)
256D PMU 1 Phase A Voltage Magnitude 0 to 999999.999 V 0.001 F060 0
256F PMU Unit 1 Phase A Voltage Angle -180 to 180 ° 0.01 F002 0
2570 PMU 1 Phase B Voltage Magnitude 0 to 999999.999 V 0.001 F060 0
2572 PMU 1 Phase B Voltage Angle -180 to 180 ° 0.01 F002 0
2573 PMU 1 Phase C Voltage Magnitude 0 to 999999.999 V 0.001 F060 0
2575 PMU 1 Phase C Voltage Angle -180 to 180 ° 0.01 F002 0
2576 PMU 1 Auxiliary Voltage Magnitude 0 to 999999.999 V 0.001 F060 0
2578 PMU 1 Auxiliary Voltage Angle -180 to 180 ° 0.01 F002 0
2579 PMU 1 Positive Sequence Voltage Magnitude 0 to 999999.999 V 0.001 F060 0
257B PMU 1 Positive Sequence Voltage Angle -180 to 180 ° 0.01 F002 0
257C PMU 1 Negative Sequence Voltage Magnitude 0 to 999999.999 V 0.001 F060 0
257E PMU 1 Negative Sequence Voltage Angle -180 to 180 ° 0.01 F002 0
257F PMU 1 Zero Sequence Voltage Magnitude 0 to 999999.999 V 0.001 F060 0
2581 PMU 1 Zero Sequence Voltage Angle -180 to 180 ° 0.01 F002 0
2582 PMU 1 Phase A Current Magnitude 0 to 999999.999 A 0.001 F060 0
2584 PMU 1 Phase A Current Angle -180 to 180 ° 0.01 F002 0
2585 PMU 1 Phase B Current Magnitude 0 to 999999.999 A 0.001 F060 0
2587 PMU 1 Phase B Current Angle -180 to 180 ° 0.01 F002 0
2588 PMU 1 Phase C Current Magnitude 0 to 999999.999 A 0.001 F060 0
258A PMU 1 Phase C Current Angle -180 to 180 ° 0.01 F002 0
258B PMU 1 Ground Current Magnitude 0 to 999999.999 A 0.001 F060 0
258D PMU 1 Ground Current Angle -180 to 180 ° 0.01 F002 0
258E PMU 1 Positive Sequence Current Magnitude 0 to 999999.999 A 0.001 F060 0
2590 PMU 1 Positive Sequence Current Angle -180 to 180 ° 0.01 F002 0
2591 PMU 1 Negative Sequence Current Magnitude 0 to 999999.999 A 0.001 F060 0
2593 PMU 1 Negative Sequence Current Angle -180 to 180 ° 0.01 F002 0
2594 PMU 1 Zero Sequence Current Magnitude 0 to 999999.999 A 0.001 F060 0
2596 PMU 1 Zero Sequence Current Angle -180 to 180 ° 0.01 F002 0
2597 PMU 1 Frequency 2 to 90 Hz 0.001 F003 0
2599 PMU 1 df/dt -327.67 to 327.67 Hz/s 0.01 F002 0
259A PMU 1 Configuration Change Counter 0 to 65535 --- 1 F001 0
259B Reserved (4 items) 0 to 1 --- 1 F001 0
Phasor Measurement Unit Integer (Read Only)
2699 PMU 1 SOC Timestamp 0 to 4294967295 seconds 1 F003 0
269B PMU 1 FRAMESEC Timestamp 0 to 4294967295 seconds 1 F003 0
269D PMU 1 STAT Flags 0 to 4294967295 --- 1 F003 0
Phasor Measurement Unit Aggregator Actual Values (Read Only)
26BD PMU 1 Aggregator PDU Size --- --- --- F001 0
IEC 61850 GGIO5 Configuration (Read/Write Setting Registers) (16 modules)
26D0 IEC 61850 GGIO5 uinteger Input 1 Operand --- --- --- F612 0
26D1 IEC 61850 GGIO5 uinteger Input 2 Operand --- --- --- F612 0
26D2 IEC 61850 GGIO5 uinteger Input 3 Operand --- --- --- F612 0
26D3 IEC 61850 GGIO5 uinteger Input 4 Operand --- --- --- F612 0
26D4 IEC 61850 GGIO5 uinteger Input 5 Operand --- --- --- F612 0
Table B–10: MODBUS MEMORY MAP (Sheet 13 of 70)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
