GE Multilin F60 Feeder Protection System B-47
APPENDIX B B.4 MEMORY MAPPING
B
78BD PMU 1 Phase A Current Test Angle -180 to 180 ° 0.05 F002 -1000
78BE PMU 1 Phase B Current Test Magnitude 0 to 9.999 kA 0.001 F004 1000
78C0 PMU 1 Phase B Current Test Angle -180 to 180 ° 0.05 F002 -13000
78C1 PMU 1 Phase C Current Test Magnitude 0 to 9.999 kA 0.001 F003 1000
78C3 PMU 1 Phase C Current Test Angle -180 to 180 ° 0.05 F002 11000
78C4 PMU 1 Ground Current Test Magnitude 0 to 9.999 kA 0.001 F004 0
78C6 PMU 1 Ground Current Test Angle -180 to 180 ° 0.05 F002 0
78C7 PMU 1 Test Frequency 20 to 70 Hz 0.001 F003 60000
78C9 PMU 1 Test df/dt -10 to 10 Hz/s 0.01 F002 0
Underfrequency (Read/Write Setting) (6 modules)
7A80 Underfrequency 1 Function 0 to 1 --- 1 F102 0 (Disabled)
7A81 Underfrequency 1 Block 0 to 4294967295 --- 1 F300 0
7A83 Underfrequency 1 Min Current 0.1 to 1.25 pu 0.01 F001 10
7A84 Underfrequency 1 Pickup 20 to 65 Hz 0.01 F001 5950
7A85 Underfrequency 1 Pickup Delay 0 to 65.535 s 0.001 F001 2000
7A86 Underfrequency 1 Reset Delay 0 to 65.535 s 0.001 F001 2000
7A87 Underfrequency 1 Source 0 to 5 --- 1 F167 0 (SRC 1)
7A88 Underfrequency 1 Events 0 to 1 --- 1 F102 0 (Disabled)
7A89 Underfrequency 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
7A8A Underfrequency 1 Reserved (5 items) 0 to 1 --- 1 F001 0
7A8F ...Repeated for Underfrequency 2
7A9E ...Repeated for Underfrequency 3
7AAD ...Repeated for Underfrequency 4
7ABC ...Repeated for Underfrequency 5
7ACB ...Repeated for Underfrequency 6
User Programmable Pushbuttons (Read/Write Setting) (16 modules)
7B60 User Programmable Pushbutton 1 Function 0 to 2 --- 1 F137 0 (Disabled)
7B61 User Programmable Pushbutton 1 Top Line --- --- --- F202 (none)
7B6B User Programmable Pushbutton 1 On Text --- --- --- F202 (none)
7B75 User Programmable Pushbutton 1 Off Text --- --- --- F202 (none)
7B7F User Programmable Pushbutton 1 Drop-Out Time 0 to 60 s 0.05 F001 0
7B80 User Programmable Pushbutton 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
7B81 User Programmable Pushbutton 1 Events 0 to 1 --- 1 F102 0 (Disabled)
7B82 User Programmable Pushbutton 1 LED Operand 0 to 4294967295 --- 1 F300 0
7B84 User Programmable Pushbutton 1 Autoreset Delay 0.2 to 600 s 0.1 F001 10
7B85 User Programmable Pushbutton 1 Autoreset Function 0 to 1 --- 1 F102 0 (Disabled)
7B86 User Programmable Pushbutton 1 Local Lock Operand 0 to 4294967295 --- 1 F300 0
7B88 User Programmable Pushbutton 1 Message Priority 0 to 2 --- 1 F220 0 (Disabled)
7B89 User Programmable Pushbutton 1 Remote Lock Operand 0 to 4294967295 --- 1 F300 0
7B8B User Programmable Pushbutton 1 Reset Operand 0 to 4294967295 --- 1 F300 0
7B8D User Programmable Pushbutton 1 Set Operand 0 to 4294967295 --- 1 F300 0
7B8F User Programmable Pushbutton 1 Hold 0 to 10 s 0.1 F001 1
7B90 ...Repeated for User Programmable Pushbutton 2
7BC0 ...Repeated for User Programmable Pushbutton 3
7BF0 ...Repeated for User Programmable Pushbutton 4
7C20 ...Repeated for User Programmable Pushbutton 5
7C50 ...Repeated for User Programmable Pushbutton 6
7C80 ...Repeated for User Programmable Pushbutton 7
7CB0 ...Repeated for User Programmable Pushbutton 8
7DE0 ...Repeated for User Programmable Pushbutton 9
7D10 ...Repeated for User Programmable Pushbutton 10
7D40 ...Repeated for User Programmable Pushbutton 11
7D70 ...Repeated for User Programmable Pushbutton 12
7DA0 ...Repeated for User Programmable Pushbutton 13
Table B–10: MODBUS MEMORY MAP (Sheet 39 of 70)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
