GE F60 - Page 592

B-54 F60 Feeder Protection System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
98C7 ...Repeated for IEC61850 GOOSE uinteger 14
98CA ...Repeated for IEC61850 GOOSE uinteger 15
98CD ...Repeated for IEC61850 GOOSE uinteger 16
FlexElement Actual Values (Read Only) (8 modules)
9900 FlexElement 1 Actual
-2147483.647 to 2147483.647
--- 0.001 F004 0
9902 FlexElement 2 Actual
-2147483.647 to 2147483.647
--- 0.001 F004 0
9904 FlexElement 3 Actual
-2147483.647 to 2147483.647
--- 0.001 F004 0
9906 FlexElement 4 Actual
-2147483.647 to 2147483.647
--- 0.001 F004 0
9908 FlexElement 5 Actual
-2147483.647 to 2147483.647
--- 0.001 F004 0
990A FlexElement 6 Actual
-2147483.647 to 2147483.647
--- 0.001 F004 0
990C FlexElement 7 Actual
-2147483.647 to 2147483.647
--- 0.001 F004 0
990E FlexElement 8 Actual
-2147483.647 to 2147483.647
--- 0.001 F004 0
Breaker Restrike (Read/Write Setting) (1 module)
9930 Breaker Restrike 1 Function 0 to 1 --- 1 F102 0 (Disabled)
9931 Breaker Restrike 1 Block 0 to 4294967295 --- 1 F300 0
9933 Breaker Restrike 1 Signal Source 0 to 5 --- 1 F167 0 (SRC 1)
9934 Breaker Restrike 1 Pickup 0.10 to 2.00 pu 0.01 F001 50
9935 Breaker Restrike 1 Reset Delay 0 to 65.535 s 0.001 F001 100
9936 Breaker Restrike 1 HF Detect 0 to 1 --- 1 F102 1 (Enabled)
9937 Breaker Restrike 1 Breaker Open 0 to 4294967295 --- 1 F300 0
9939 Breaker Restrike 1 Open Command 0 to 4294967295 --- 1 F300 0
993B Breaker Restrike 1 Close Command 0 to 4294967295 --- 1 F300 0
993D Breaker Restrike 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
993E Breaker Restrike 1 Events 0 to 1 --- 1 F102 0 (Disabled)
993F Reserved (2 items) --- --- --- F002 0
Teleprotection Inputs/Outputs Commands (Read/Write Command)
9980 Teleprotection Clear Lost Packets 0 to 1 --- 1 F126 0 (No)
Teleprotection Inputs/Outputs (Read/Write Settings)
9990 Teleprotection Function 0 to 1 --- 1 F102 0 (Disabled)
9991 Teleprotection Number of Terminals 2 to 3 --- 1 F001 2
9992 Teleprotection Number of Channels 1 to 2 --- 1 F001 1
9993 Teleprotection Local Relay ID 0 to 255 --- 1 F001 0
9994 Teleprotection Terminal 1 ID 0 to 255 --- 1 F001 0
9995 Teleprotection Terminal 2 ID 0 to 255 --- 1 F001 0
9996 Reserved (10 items) 0 to 1 --- 1 F001 0
9A00 Teleprotection Input 1-n Default States (16 items) 0 to 3 --- 1 F086 0 (Off)
9A10 Teleprotection Input 2-n Default States (16 items) 0 to 3 --- 1 F086 0 (Off)
9A20 Teleprotection Output 1-n Operand (16 items) 0 to 4294967295 --- 1 F300 0
9A40 Teleprotection Output 2-n Operand (16 items) 0 to 4294967295 --- 1 F300 0
Teleprotection Channel Tests (Read Only)
9AA0 Teleprotection Channel 1 Status 0 to 2 --- 1 F134 1 (OK)
9AA1 Teleprotection Channel 1 Number of Lost Packets 0 to 65535 --- 1 F001 0
9AA2 Teleprotection Channel 2 Status 0 to 2 --- 1 F134 2 (n/a)
9AA3 Teleprotection Channel 2 Number of Lost Packets 0 to 65535 --- 1 F001 0
9AA4 Teleprotection Network Status 0 to 2 --- 1 F134 2 (n/a)
9AAF Teleprotection Channel 1 Input States 0 to 1 --- 1 F500 0
9AB0 Teleprotection Channel 2 Input States 0 to 1 --- 1 F500 0
9AC0 Teleprotection Input 1 States, 1 per register (16 items) 0 to 1 --- 1 F108 0 (Off)
9AD0 Teleprotection Input 2 States, 1 per register (16 items) 0 to 1 --- 1 F108 0 (Off)
Cold Load Pickup (Read/Write Setting) (2 modules)
A000 Cold Load Pickup 1 Function 0 to 1 --- 1 F102 0 (Disabled)
A001 Cold Load Pickup 1 Initiate 0 to 4294967295 --- 1 F300 0
A003 Cold Load Pickup 1 Block 0 to 4294967295 --- 1 F300 0
A005 Outage Time Before Cold Load Pickup 1 0 to 1000 s 1 F001 1000
Table B–10: MODBUS MEMORY MAP (Sheet 46 of 70)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
