GE Multilin F60 Feeder Protection System B-53
APPENDIX B B.4 MEMORY MAPPING
B
93D8 ...Repeated for DCmA Output 21
93DE ...Repeated for DCmA Output 22
93E4 ...Repeated for DCmA Output 23
93EA ...Repeated for DCmA Output 24
Direct Input/Output Names (Read/Write Setting) (32 modules)
9400 Direct Input 1 Name 0 to 96 --- 1 F205 “Dir Ip 1”
9406 Direct Output 1 Name 1 to 96 --- 1 F205 “Dir Out 1”
940C ...Repeated for Direct Input/Output 2
9418 ...Repeated for Direct Input/Output 3
9424 ...Repeated for Direct Input/Output 4
9430 ...Repeated for Direct Input/Output 5
943C ...Repeated for Direct Input/Output 6
9448 ...Repeated for Direct Input/Output 7
9454 ...Repeated for Direct Input/Output 8
9460 ...Repeated for Direct Input/Output 9
946C ...Repeated for Direct Input/Output 10
9478 ...Repeated for Direct Input/Output 11
9484 ...Repeated for Direct Input/Output 12
9490 ...Repeated for Direct Input/Output 13
949C ...Repeated for Direct Input/Output 14
94A8 ...Repeated for Direct Input/Output 15
94B4 ...Repeated for Direct Input/Output 16
94C0 ...Repeated for Direct Input/Output 17
94CC ...Repeated for Direct Input/Output 18
94D8 ...Repeated for Direct Input/Output 19
94E4 ...Repeated for Direct Input/Output 20
94F0 ...Repeated for Direct Input/Output 21
94FC ...Repeated for Direct Input/Output 22
9508 ...Repeated for Direct Input/Output 23
9514 ...Repeated for Direct Input/Output 24
9520 ...Repeated for Direct Input/Output 25
952C ...Repeated for Direct Input/Output 26
9538 ...Repeated for Direct Input/Output 27
9544 ...Repeated for Direct Input/Output 28
9550 ...Repeated for Direct Input/Output 29
955C ...Repeated for Direct Input/Output 30
9568 ...Repeated for Direct Input/Output 31
9574 ...Repeated for Direct Input/Output 32
IEC 61850 Received Integers (Read/Write Setting) (16 modules)
98A0 IEC 61850 GOOSE uinteger 1 Default Value 0 to 429496295 --- 1 F003 1000
98A2 IEC 61850 GOOSE uinteger Input 1 Mode 0 to 1 --- 1 F491 0 (Default
Value)
98A3 ...Repeated for IEC61850 GOOSE uinteger 2
98A6 ...Repeated for IEC61850 GOOSE uinteger 3
98A9 ...Repeated for IEC61850 GOOSE uinteger 4
98AC ...Repeated for IEC61850 GOOSE uinteger 5
98AF ...Repeated for IEC61850 GOOSE uinteger 6
98B2 ...Repeated for IEC61850 GOOSE uinteger 7
98B5 ...Repeated for IEC61850 GOOSE uinteger 8
98B8 ...Repeated for IEC61850 GOOSE uinteger 9
98BB ...Repeated for IEC61850 GOOSE uinteger 10
98BE ...Repeated for IEC61850 GOOSE uinteger 11
98C1 ...Repeated for IEC61850 GOOSE uinteger 12
98C4 ...Repeated for IEC61850 GOOSE uinteger 13
Table B–10: MODBUS MEMORY MAP (Sheet 45 of 70)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
