B-62 F60 Feeder Protection System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
B5C8 IEC 61850 Configurable GOOSE ConfRev (Configuration
Revision)
1 to 4294967295 --- 1 F003 1
B5CA IEC 61850 Configurable GOOSE Retransmission Curve 0 to 3 --- 1 F611 3 (Relaxed)
B5CB Configurable GOOSE Dataset Items for Transmission
(64 items)
0 to 1008 --- 1 F616 0 (None)
B60B ...Repeated for module number 2
B676 ...Repeated for module number 3
B6E1 ...Repeated for module number 4
B74C ...Repeated for module number 5
B7B7 ...Repeated for module number 6
B822 ...Repeated for module number 7
B88D ...Repeated for module number 8
IEC 61850 Configurable GOOSE Reception (Read/Write Setting) (16 modules)
B900 Configurable GOOSE Dataset Items for Reception
(32 items)
0 to 197 --- 1 F233 0 (None)
B920 ...Repeated for module number 2
B940 ...Repeated for module number 3
B960 ...Repeated for module number 4
B980 ...Repeated for module number 5
B9A0 ...Repeated for module number 6
B9C0 ...Repeated for module number 7
B9E0 ...Repeated for module number 8
BA00 ...Repeated for module number 9
BA20 ...Repeated for module number 10
BA40 ...Repeated for module number 11
BA60 ...Repeated for module number 12
BA80 ...Repeated for module number 13
BAA0 ...Repeated for module number 14
BAC0 ...Repeated for module number 15
BAE0 ...Repeated for module number 16
Contact Inputs (Read/Write Setting) (96 modules)
BB00 Contact Input 1 Name --- --- --- F205 “Cont Ip 1“
BB06 Contact Input 1 Events 0 to 1 --- 1 F102 0 (Disabled)
BB07 Contact Input 1 Debounce Time 0 to 16 ms 0.5 F001 20
BB08 ...Repeated for Contact Input 2
BB10 ...Repeated for Contact Input 3
BB18 ...Repeated for Contact Input 4
BB20 ...Repeated for Contact Input 5
BB28 ...Repeated for Contact Input 6
BB30 ...Repeated for Contact Input 7
BB38 ...Repeated for Contact Input 8
BB40 ...Repeated for Contact Input 9
BB48 ...Repeated for Contact Input 10
BB50 ...Repeated for Contact Input 11
BB58 ...Repeated for Contact Input 12
BB60 ...Repeated for Contact Input 13
BB68 ...Repeated for Contact Input 14
BB70 ...Repeated for Contact Input 15
BB78 ...Repeated for Contact Input 16
BB80 ...Repeated for Contact Input 17
BB88 ...Repeated for Contact Input 18
BB90 ...Repeated for Contact Input 19
BB98 ...Repeated for Contact Input 20
BBA0 ...Repeated for Contact Input 21
BBA8 ...Repeated for Contact Input 22
Table B–10: MODBUS MEMORY MAP (Sheet 54 of 70)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
