Peripherals Installation
LOGIQ C9 Series – Basic Service Manual 3-33
5482298-100 English Rev. 5
ECG Installation
Tools
No special tools needed.
Manpower
One person 5 min.
Preparations
1. Unpack the ECG.
2. Ensure no physical damage.
Installation Procedure
1. Connect the ECG to the USB port on the LOGIQ C9 Series
system.
Figure 3-11. Connect ECG to the system
