System Setup
3-26 LOGIQ C9 Series – Basic Service Manual
5482298-100 English Rev. 5
Peripherals Installation Instructions
Sony UP-D897MD Printer Installation
Tools
No special tools needed.
Manpower
One person 5 min.
Preparations
1. Unpack B/W Printer.
Installation Procedure
NOTE: The printer driver is customized for the LOGIQ C9 Series at the
factory; you do not need to change the settings.
1. Place the device in a suitable place.
2. Connect power cord and USB Cable on the Printer.
3. Connect the power cord with the AC output on the rear
panel of LOGIQ C9 Series, then turn on the printer.
4. Connect the printer to the USB port.
Figure 3-4. Connect UP-D897MD to LOGIQ C9 Series
To Next Page
