Renewal Parts
9-4 LOGIQ C9 Series – Basic Service Manual
5482298-100 English Rev. 5
Renewal Parts Lists
ACDC Power Pack
Operator Console Assy
The following figure illustrates what is the front side (1), left side
(2), back/Rear side (3), right side (4) of the system.
Figure 9-1. Operator Console Assy
Table 9-2: ACDC Power Pack & ACDC Power Cable List
Item
Part
Number
Part Name Quantity FRU
001 5460229 ACDC Adapter with Clamp Filter 1 1
