GE HEALTHCARE
DIRECTION 5394141, REVISION 5 LOGIQ™ P5 SEVICE MANUAL
8-210 Section 8-7 - Mechanical Option Installation instruction
8-7-14 Printer VCR DVD Fixture Top Installation (MD-800) (cont’d)
7.) Install DVD hide bracket by screwing 2 screws(2159633, BH M4x8).
Figure 8-317 Printer VCR DVD Fixture Top installation (LQ MD800)
