DIRECTION 5394141, REVISION 5 LOGIQ™ P5 SEVICE MANUAL
Section 9-9 - Cables 9-19
710 Peripheral AC Power Cable 5165244
Connect one side (Label
CON5) to Label CON5 of
LP5 AC Out Cable
and another side (Label:
CON6) to Label CON6 of
LP5 ARP Assy
11YesYes Yes Yes
711 AEXP Cable 5172066
Connect one side (Label
J13) to Label PCB Silk J13
of LP5 Syscon Assy
and another side (Label:
J15) to Label J15 of LP5
ARP Assy
11YesYes Yes Yes
712 DCWD Cable Assy 5174403
Connect one side to DCWD
Bracket and another
side(Label: J7) to PCB Silk
J7 of ACWD Assy
11YesYes Yes Yes
713 IEC Type ECG CABLE 5341188
ECG Patient Cable only for
Japan
11YesYes Yes Yes
714 AHA Type ECG CABLE 5341189
ECG Patient Cable for Asia,
US, and Europe.
11YesYes Yes Yes
Item Part Name FRU Number Description Qty FRU R1.0.X R2.0.X R3.0.X~ R4.0.X~
Table 9-9 Cables
