GE HEALTHCARE
DIRECTION 5394227, 12 LOGIQ S8/LOGIQ E8 SERVICE MANUAL
7 - 40 Section 7-5 - Gathering Troubleshooting Data (R4.2.5x and later)
7-5-4 Collecting a screen capture with logs
If the LOGIQ™ S8 malfunctions, simultaneously press the Alt+D keys. Alt+D is available at all times
and collects a screen capture of the image monitor, user-defined presets, and these logs:
• Keyboard Shadow Log (protected information)
• Error Logs
• Crash Log (protected information)
• Vital Product Data
• DICOM Logs
• Windows Event Logs
• Windows Modem Log
• Diagnostic Logs
• Service Logs
For a detailed list of Service Logs captured,
see 7-3-7 "Capturing Network Logs with Network Sniffer" on page 7-14.
Figure 7-44 ALT+D Dialog Box
