GE MAC 2000 Service Manual

Maintenance
3.Connectthecablesandharnesses,identiedinthefollowingphotograph,
tothePWA.
4.Positionthepowersupply/KISSpumpbaseonthechassis.
5.Securethepowersupply/KISSpumpbasetothechassisusingitsfasteners,as
identiedinthefollowingphotograph.
6.Ifitwasinstalled,replacetheKISSpumpandtubing.
Seestep1throughstep4in“ReplacingtheKISSPumpAssembly”onpage127
forinstructions.
7.Replacethepowersupplyassembly.
Seestep1throughstep4in“ReplacingthePowerSupplyAssembly”onpage
92forinstructions.
8.Reattachthetopcoverassembly.
See“ReattachingtheTopCoverAssemblytotheDevice”onpage81for
instructions.
9.Reinsertthebattery.
Seestep6throughstep8in“ReplacingtheBattery”onpage74forinstructions.
10.ContinuewiththeappropriatefunctionalcheckoutprocedureforthisFRU.
See“FunctionalCheckout”onpage129formoreinformation.
