5-16
MAC
TM
600
Revision G
2047426-002
Parts and Replacements:
Ordering Parts
FRU - Cover Battery - Expedition
2047333-001
FRU - COVER BATTERY - EXPEDITION
Table 5-16. FRU - Cover Battery - Expedition
ITEM
ITEM DESCRIPTION
1
COVER BATTERY - EXPEDITION
2
BUMPON SJ-6125, 15.9MM DIA, 6.35MM THK
99
101
