Maintenance: Preparing System for FRU Replacement
Required Tools and Manuals
PWA Connector Details
The legends for the PWA Connectors (J1, J2 etc) for the new PWA FRU
2066447-002 are different as compared with the old PWA FRU 2047330-
001. Refer the following table for the old and new connector legends:
Table 4-1. Required tools and manuals
Sl no:
Description
1 Phillips screwdriver
2 Anti-static wrist strap
3 Service manual as needed for reference
4 Safety tester for measurements according to 60601-1
5 Connecting wires and clips required for electrical
safety tests (optionl)
6 Multi-meter
7 Multi Lead ECG simulator
8 MAC 600 Operator’s Manual for reference
9 Nose Plier
10 Recommended SD card
Table 4-2. PWA Connectors
Connector Description
OLD PWA FRU
PN: 2047330-001
NEW PWA FRU
PN:2066447-002
Key sheet J4 J7
Display J5 J6
Printer J10 J5
SD Card J1 J3
Power In W1 W1
RS232 J2 J2
JATAG J3 J8
USB J9 J1
Modem J12 J9
