A-2 MAC
TM
600 Revision G
2047426-002
Technical Specification:
Instrument Type
Microprocessor augmented automatic electrocardiograph; 10-leadwire, 12 lead simultaneous acquisition with programmable lead
configuration.
Processing
ECG Interpretation: Marquette 12SL ECG Analysis Program for Adults and Pediatrics
Computerized measurements: 12-lead analysis
ECG analysis frequency: 500 samples/second (sps)
ECG storage: Optional. 200 ECGs in external memory (SD card)
Digital sampling rate: 2,000 samples/second/channel
ECG on-screen preview: On-screen preview of acquired 10 second ECG waveform and optional 12SL measurement and
interpretation.
Pre-acquisition: Provides 10 seconds of instantaneous ECG acquisition (after 10 seconds from boot up)
Dynamic range: AC Differential ± 5mV, DC offset ±300 mV
Resolution: 4.88 µV/LSB @ 500 sps
Frequency response: –3 dB @ 0.01 to 150 Hz
Low cut off frequency: 0.01 Hz, 0.02 Hz, 0.16 Hz or 0.32 Hz (-3 dB limits)
High cut off frequency: Configurable at 20 Hz, 40 Hz, 100 Hz or 150 Hz
Common mode rejection: >100 dB (with AC filter switched on)
Input impedance: >100M @ 10Hz, defibrillator protected
Patient leakage: <10 µA
Special acquisition functions: Disconnected lead detection except RL, excessive AC noise, baseline wander and muscle tremor
messages
Heart rate meter: 30 to 300 BPM ±10% or ±5 BPM, whichever is greater. Heart rates outside this range will not be
displayed
Start-up time Less than 7 seconds
Patient Information
Supported patient information Patient ID, Secondary ID, Age, Date of Birth, Gender.
Alphanumeric entry in T9 type for patient ID and secondary ID.
Communication (optional)
MUSE Cardiology Information System compatible
Serial cable ECG Transmission to MUSE Cardiology Information System
Serial cable ECG transmission in XML format
Cardiosoft interface
