Chapter 5. Specifications
Moisture Target Series 6 User’s Manual 85
Chapter 5. Specifications
5.1 Electronics
Input:
moisture signal from GE thin-film aluminum oxide moisture sensor on
an M Series probe or a VeriDri probe
Intrinsic Safety:
external safety barrier for moisture input (optional)
Analog Output:
single, isolated recorder output for dew point,
internally optically isolated, 10-bit (0.1%) resolution
0–2 V: 10 kminimum load resistance
0–20 mA: 400 maximum series resistance
4–20 mA: 400 maximum series resistance
Outputs are user-programmable within the range of the instrument and
the corresponding probe.
Alarm Relays:
1 fault alarm and 2 programmable high/low alarms:
Standard designs are available for the high/low alarms, set to trip at any
level within the range of the instrument, and programmable from the
front panel.
Form C SPDT Relays: Standard
3A @ 250VAC
3A @ 30VDC
