CHAPTER 6: ACTUAL VALUES
489 GENERATOR MANAGEMENT RELAY – INSTRUCTION MANUAL 6–21
6.3.7 Speed
PATH: ACTUAL VALUES ZV A2 METERING DATA ZV SPEED
If the Tachometer function is assigned to one of the digital inputs, its speed be viewed here.
If no digital input is configured for tachometer, the
THIS FEATURE NOT PROGRAMMED
flash message will appear when an attempt is made to enter this group of messages.
îš„ SPEED [Z] TACHOMETER: 0 RPM
Range: 0 to 7200 RPM
