4–12 489 GENERATOR MANAGEMENT RELAY – INSTRUCTION MANUAL
CHAPTER 4: INTERFACES
FIGURE 4–3: Communications using Rear RS485 Port
4.2.3 Installing the EnerVista 489 Setup Software
The following minimum requirements must be met for the EnerVista 489 Setup software to
operate on your computer.
• Pentium class or higher processor (Pentium II 400 MHz or better recommended)
• Microsoft Windows 95, 98, 98SE, ME, NT 4.0 (SP4 or higher), 2000, XP
• Internet Explorer version 4.0 or higher (required libraries)
• 128 MB of RAM (256 MB recommended)
• Minimum of 200 MB hard disk space
A list of qualified modems for serial communications is shown below:
• US Robotics external 56K Faxmodem 5686
• US Robotics external Sportster 56K X2
• PCTEL 2304WT V.92 MDC internal modem
After ensuring these minimum requirements, use the following procedure to install the
EnerVista 489 Setup software from the enclosed GE EnerVista CD.
